B-10
Monitoring accuracy (O
2
Therapy)
Continuous Flow ± (2 L/min+ 10 % of the actual reading)(BTPS)
O
2
Concentration ± (2.5 Vol. % + 2.5% of the actual reading)
B.8 Alarms
B.8.1 Settable Alarms
Alarm settings
Parameter Setting range Automatic threshold Notes
TV High limit 110 to 4000 mL, OFF (Adult)
25 to 600mL, OFF (Pediatric)
1.5 × TVe average
value
High limit
is greater
than low
limit.
Low limit 50 to 4000 mL, OFF (Adult)
10 to 600mL, OFF (Pediatric)
0.5 × TVe average
value
MV High limit
Pediatric: 0.2 to 60.0 L/min
Adult: 0.2 to 100.0 L/min
1.5 × MV monitored
value
Low limit Pediatric: 0.1 to 30.0 L/min
Adult: 0.1 to 50.0 L/min
0.6 × MV monitored
value
FiO
2
High limit
Low-pressure oxygen:
20 Vol.% to 100 Vol.%
100 Vol.%
Low limit
Low-pressure oxygen:
1 8 Vo l . % t o 9 8 Vo l . %
21 Vol.%
Paw High limit 10 to 85 cmH
2
O Average peak
pressure+10 cmH
2
O
or 35 cmH
2
O,
whichever is greater
/
ftotal High limit 1 to 150, OFF 1.4 × ftotal monitored
value
/
Tapnea 5 to 60s 15 /
