Mindray SV300 - Install the O Sensor

3-15
3.8 Install the O
2
Sensor
CAUTION
 To reduce the risk of explosion, do not burn the O
2
cell or force the cell open.
A. O
2
sensor door B. O
2
sensor
C. Fixing seat D. O
2
sensor connection cable
1. Rotate the O
2
sensor clockwise to install it.
2. Push the O
2
sensor and its fixing seat into the ventilator.
3. Connect the O
2
sensor connection cable.
4. Close the O
2
sensor door.
A
C
B
D
