B-6
Leakage
Leakage
Not greater than 200 mL/min@50 cmH
2
O (adult tubes)
Not greater than 100 mL/min@40 cmH
2
O (pediatric tubes)
Not greater than 50 mL/min@20 cmH
2
O (infant tubes)
B.6 Ventilator Specifications
Controlled parameters
Parameter Range Step Unit
O
2
% 21 to 100 1 Vol. %
TV Adult: 100 to 2000(BTPS)
Pediatric: 20 to 300(BTPS)
Adult: 10
Pediatric: 1
mL
f 1 to 100 1 bpm
fsimv 1 to 60 1 bpm
Tinsp 0.20 to 10.00 0.05 s
I:E 4:1 to 1:10 0.5 /
Tslope 0.00 to 2.00 0.05 s
Tpause(%) OFF, 5 to 60 5 %
PEEP OFF, 1 to 45 1 cmH
2
O
△Pinsp 5 to 80 1 cmH
2
O
△Psupp 0 to 80 1 cmH
2
O
Phigh 0 to 80 1 cmH
2
O
Plow 0 to 45 1 cmH
2
O
Thigh 0.2 to 30.0 0.1 s
Tlow 0.2 to 30.0 0.1 s
Trigger 0.5 to 15.0 0.1 L/min
-10.0 to -0.5 0.5 cmH
2
O
Assist ON, OFF / /
△int.PEEP OFF, 1 to 45 1 cmH
2
O
Exp% Auto, 10 to 85 5 %
△Papnea Provides pressure apnea setting. Refer to △Pinsp specification.
fapnea 1 to 80 1 bpm
TVapnea Adult: 100 to 2000 (BTPS)
Pediatric: 20 to 300 (BTPS)
Adult: 10
Pediatric: 1
mL
Apnea Tinsp 0.20 to 10.00 0.05 s
MV% 25 to 350 1 %
Tube I.D. Adult: 5.0 to 12.0 0.5 mm
