11.2.6 Patient Tubing
WARNING
To minimize the risk of bacterial contamination or physical damage, remove and
install the bacterial filter with care.
CAUTION
When removing the reusable patient tubing, disconnect the tubes from the
ventilator connectors instead of pulling the tubes.
A. Inspiratory filter B. Expiratory filter
C. Inspiratory water trap D. Expiratory water trap
E. Heat & Moisture Exchange (HME) F. Support arm hook
F
D
C
A
B
E
