11.2.8 Humidifier
NOTE
 The humidifier shall comply with the requirements of ISO 8185. The humidifier
assembly, its installation and disassembling steps described in this section are only
for reference.
11.2.9 Humidifier on the Ventilator
A. Humidifier B. Humidifier mounting plate C. Humidifier bracket slot
D. Screw E. Humidifier inlet F. Humidifier outlet
B
A
C
D
E
F
