Mindray SV300 User Manual

B-14
Sidestream CO
2
alarm
limits
Range Step
EtCO
2
high limit 2 to 99 mmHg
1 mmHg
EtCO
2
low limit 0 to 97 mmHg
Sidestream CO
2
environmental specifications
Item Temperature (ºC)
Relative humidity
(non-condensing)
Barometric
pressure (kPa)
Operating 5 to 40 10 to 95 % 70 to 106
Storage and transport –20 to +60 10 to 95 % 50 to 106
B.10.2 Mainstream CO
2
Module
CO
2
module
Measurement range and
accuracy
Measurement range Accuracy
0 to 40 mmHg ±2 mmHg
41 to 70 mmHg ±5 % of the actual reading
71 to100 mmHg ±8 % of the actual reading
101 to 150 mmHg ±10 % of the actual reading
Measurement accuracy drift
According to the test method of the standard ISO 80601-2-55, the
module meets the requirement for measurement accuracy in this
table.
Resolution 1 mmHg
Monitored parameters
Parameters Range Resolution
slopeCO
2
0 to 9.99 % /L 0.01 % /L
Vtalv 0 to 9999 mL 1 mL
V’alv 0 to 20 L/min
0.01 L/min for < 1
L/min
0.1 L/min for ≥ 1
L/min
V’CO
2
0 to 9999 mL
/min
1 mL/min
Vdaw 0 to 999 mL 1 mL
Vdaw/TVe 0 to 100 % 1 %
VeC O
2
0 to 999 mL 1 mL
ViCO
2
0 to 999 mL 1 mL
Total system response time <2.0 s

Mindray SV300 Specifications

General

Waveform Display	Pressure, Flow, Volume
Battery Backup	Up to 2 hours
Ventilation Modes	VCV, PCV, SIMV
Tidal Volume Range	20 to 2000 mL
FiO2	21 to 100%
Inspiratory Time	0.2-5.0 s
Monitoring Parameters	Paw, Ppeak, Pmean, Pplat, PEEP, VTI, VTE, MV, f, FiO2, I:E
Alarms	High/Low Airway Pressure, High/Low Minute Volume, High/Low Tidal Volume, High/Low Respiratory Rate, High/Low FiO2, Apnea, Power Failure
Power Supply	AC 100-240V, 50/60Hz
Peak Flow	180 L/min
Trigger Sensitivity (Flow)	0.5-10 L/min
