E-1
E Factory Defaults
This chapter lists the most important factory default settings which are not user-adjustable.
When necessary, you can restore the factory default settings.
E.1 Screen
Setting Factory default setting
Setup-screen setup-waveform count 3
Setup-screen setup-Draw Wave Curve
Setup-screen setup- Value Count 9
E.2 Setup
Setting Factory default setting
Brightness/Volume-Key volume 2
Brightness/Volume-LCD brightness 5
System-Tinsp/I:E Tinsp
System – Height/IBW Height
System – DuoLevel Timing Thigh
System-IV Apnea Mode Pressure Control
System -TV/IBW 7 mL/kg
Sensor-O
2
- O
2
Monitoring ON
Time-date 2012.01.01
Time-time 00:00:00
Time-date format YYYY-MM-DD
Time-time format 24 h
E.3 CO
2
Module
CO
2
module Factory default setting
Monitoring ON
Pump rate 100 mL/min
BTPS compensation OFF
Max hold 10 s
