Mindray SV300 User Manual

4-13
4.5.2.1 About Graphic Trend
 Graphic Trend displays the time and date on the horizontal axis.
 Graphic Trend displays the parameter data on the vertical axis.
 Graphic Trend displays the most recent trend data on the rightmost side.
 Graphic Trend is not stored when the machine is in standby status.
 The system can display a rolling 72 hours of continuous trend data.
 Graphic Trend highlights the parameter data in the corresponding alarm color if an
alarm condition existed for the parameter at the time of trend record storage.
4.5.2.2 Navigating in Graphic Trend
Button Function
Moves the cursor one record back/forward from its current position.
Moves the cursor up/down one parameter from its current position.
Moves the cursor one page back/forward from its current position.
Moves the cursor up/down one page from its current position.
Moves the cursor to the oldest/newest record from its current position.

Mindray SV300 Specifications

General

Waveform Display	Pressure, Flow, Volume
Battery Backup	Up to 2 hours
Ventilation Modes	VCV, PCV, SIMV
Tidal Volume Range	20 to 2000 mL
FiO2	21 to 100%
Inspiratory Time	0.2-5.0 s
Monitoring Parameters	Paw, Ppeak, Pmean, Pplat, PEEP, VTI, VTE, MV, f, FiO2, I:E
Alarms	High/Low Airway Pressure, High/Low Minute Volume, High/Low Tidal Volume, High/Low Respiratory Rate, High/Low FiO2, Apnea, Power Failure
Power Supply	AC 100-240V, 50/60Hz
Peak Flow	180 L/min
Trigger Sensitivity (Flow)	0.5-10 L/min
