8.4.1 Onsite Maintenance Tools
The following table lists the tools required for troubleshooting.
Name Quantity P/N
Negative pressure ball 1 040-000814-00*
Syringe (100 ml) 1 040-000040-00*
Test fixture of the circuit transit adapter 1 115-002452-00*
Test fixture of the pressure sampling tube of the flow sensor 1 115-002456-00*
Test fixture of the vaporizer support 1 115-002453-00*
1 MPa (10 bar) test pressure gauge 1 0611-30-67602*
T-shape hexagon screw wrench (4x100) 1 M90-100111---*
3106-04-06 adapter connector 1 M6Q-030068---*
3106-06-08 adapter connector 1 M6Q-030051---*
3106-10-00 adapter connector 2 082-000021-00*
3106-06-00 adapter connector 1 M6Q-030059---*
Air tube adapter connector 1 115-002454-00*
3126-04-00 tube plug 2 082-000023-00*
3126-06-00 tube plug 3 M6Q-120001---*
3126-08-00 tube plug 4 M6Q-120002---*
3126-10-00 tube plug 3 082-000022-00*
Y-shape tube 2 M90-100030---*
Y-shape air tube 1 M6Q-030028---*
3140-08-00 Y-shape tube 1 M6Q-030025---*
PU tube (4X200) 1 M6G-020046---*
PU tube (6X100) 1
M6G-020026---*
PU tube (6X200) 1
PU tube (6X300) 1
PU tube (8X200) 2 M6G-020014---*
Air tube 4 M6G-020017---*
