Pin No. Signal Name Discription
67)
RSVD_IN1_IN Backup detection signal
68)
FAN_PWM2_OUT Fan control signal 2
69)
FAN_PWM1_OUT Fan control signal 1
70)
RSVD_OUT1_OUT Safety valve control signal
71)
TPPWR_CTRLOUT TouchPad supply control signal
72)
GND Ground
73)
RXD3_IF Series port received signal (reserved)
74)
TXD3_IF Series port sent signal (reserved)
75)
GND Ground
76)
RXD_VPM Series port sent signal (with VPM)
77)
TXD_VPM
Series port received signal (with
VPM)
78)
GND Ground
79)
RXD_VCM
Series port received signal (with
VCM)
80)
TXD_VCM Series port sent signal (with VCM)
81)
GND Ground
82)
LCD_LVDS_Y3P LVDS data signal
83)
LCD_LVDS_Y3M LVDS data signal
84)
GND Ground
85)
LCD_LVDS_CKLP LVDS clock signal
86)
LCD_LVDS_CKLM LVDS clock signal
87)
GND Ground
88)
LCD_LVDS_Y2P LVDS data signal
89)
LCD_LVDS_Y2M LVDS data signal
90)
GND Ground
91)
LCD_LVDS_Y1P LVDS data signal
92)
LCD_LVDS_Y1M LVDS data signal
93)
GND Ground
94)
LCD_LVDS_Y0P LVDS data signal
95)
LCD_LVDS_Y0M LVDS data signal
96)
GND Ground
