11
To C SD−581−15
Terminal pitch 9.5 mm
Suitable crimp−type
terminal lugs：1.25−4or2−4
B−304 Internal terminal connection
To Load cell
WHT
RED BLU
GRN
YEL(shield)
RED
BLU WHT GRN YEL(shield)
ii) In case of application of CAB−501(6 cores cable)
Junction box
B−304
CAB−501
※3 (Length of CAB−501 should be
within 100 m totally.)
3m
RED
WHT
※1GRN ※1BLU
Shield
ORN
BLK
Enlarged figure for connecting section
RED
WHT
※1BLU
Shield
※1GRN
ORN BLK
B−304 Internal terminal connections
to CSD−581−15
to Load cell
Terminal pitch 9.5 mm
RED BLU WHT
GRN
YEL(shield)
WHT ORN
RED
BLU
BLK GRN
YEL(shield)
Suitable crimp−type
terminal lugs：1.25−4or2−4
CN202
DIP202
DIP203
