EBC10
With 0.5l bottle (default) With 2.0l bottle (option)
Total=Required space with bottle on the left 339,00 339,00 Total=Required space with bottle on the left
Add. for bottle, sensor holder & belt (front) 54,00 86,00 Add. for bottle, sensor holder & belt (front)
Total=Required space with bottle on the front 393,00 425,00 Total=Required space with bottle on the front
EBC11
With 0.5l bottle (default) With 2.0l bottle (option)
Width (mm)
EBC 378,50 378,50 EBC
Edge dist. (right) includ. silicone pipe & cable (left) 50,00 50,00 Edge dist. (right) includ. silicone pipe & cable (left)
Total=Required space with bottle on the front 428,50 428,50 Total=Required space with bottle on the front
Bottle with sensor holder & belt (left) 83,00 115,00 Bottle with sensor holder & belt (left)
Total=Required space with bottle on the left 511,50 543,50 Total=Required space with bottle on the left
Height (mm)
EBC 133,50 133,50 EBC
Edge distance (top) 50,00 50,00 Edge distance (top)
Required space 183,50 183,50 Total without bottle
Bottle (apart; highest point) 138,00 215,00 Bottle (apart; highest point)
Space for silicone pipe (top) 5,00 5,00 Space for silicone pipe (top)
Total with bottle, without requ. edge distance 143,00 220,00 Required space
Depth (mm)
EBC (includ. hosepipe fittings & screws) 238,00 238,00 EBC (includ. hosepipe fittings & screws)
Space for hosepipes (back), plugs & cables (front)
23
126,00 126,00 Space for hosepipes (back), plugs & cables (front)
23
Total=Required space with bottle on the left 364,00 364,00 Total=Required space with bottle on the left
Add. for bottle, sensor holder & belt (front) 54,00 86,00 Add. for bottle, sensor holder & belt (front)
Total=Required space with bottle on the front 418,00 450,00 Total=Required space with bottle on the front
EBC12
With 0.5l bottle (option) With 2.0l bottle (default)
Width (mm)
EBC 482,00 482,00 EBC
Edge distances (right & left) 100,00 100,00 Edge distances (right & left) includ. protruding bottle
Total=Required space 582,00 582,00 Total=Required space
Height (mm)
EBC 138,00 138,00 EBC
Edge distance (top) 50,00 50,00 Edge distance (top)
Required space 188,00 188,00 Total without bottle
Bottle (apart; highest point) 138,00 215,00 Bottle (apart; highest point)
Space for silicone pipe (top) 5,00 5,00 Space for silicone pipe (top)
Total with bottle, without requ. edge distance 143,00 220,00 Required space
Depth (mm)
EBC (includ. hosepipe fittings & screws) 238,00 238,00 EBC (includ. hosepipe fittings & screws)
Space for hosepipes (back), plugs, cables, silicone pipe (front)
23
156,00 156,00 Space for hosepipes (back), plugs, cables, silicone pipe (front)
23
Add. for bottle, sensor holder & belt (front) 54,00 86,00 Add. for bottle, sensor holder & belt (front)
Total=Required space 448,00 480,00 Total=Required space
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 24.11.2014. Subject
to modification.
