9 TECHNICAL DATA
9.1 Figures
EBC10 EBC11 EBC12
Recommended max. volume of the case (per connected EBC)
14
3m
3
5m
3
10m
3
Exemplarily achievable min. dehumidification capacity at ambient conditions of 25ºC, 50%RH
14,15
4,0g/h 6,0g/h 7,0g/h
Exemplarily achievable min. humidification capacity at ambient conditions of 25ºC, 50%RH
14,15
4,0g/h 6,0g/h 7,0g/h
Exemplarily achievable setpoint range at ambient conditions of 22ºC, 50%RH
14,16
30-75%RH
Theoretical (adjustable) setpoint range 15-85%RH
Permissible highest value for the rel. humidity inside the case (the EBC issues a signal error if beyond) 94%RH
Permissible lowest value for the rel. humidity inside the case (the EBC issues a signal error if beyond) 6%RH
Airflow at the air inlet of the case
14,17
2,00m/s 2,30m/s 3,00m/s
Permissible ambient conditions for operation and storage of an EBC
18
5-35ºC, 15-80%RH, non-condensing
Permissible ambient conditions for the storage of the RH/T sensor 10-50ºC, 20-60%RH, non-condensing
Tolerance
14,19
- at a setpoint of 30%RH typically achievable +/-2%RH, max. +/-3%RH
- at a setpoint of 75%RH typically achievable +/-3%RH, max. +/-5%RH
Mains connection
20
100-240VAC, 50-60Hz
System voltage 12VDC
Power consumption max. 100W max. 200W
Weight (device without accessories, bottle, hosepipes or cables etc) 6,6kg 8,8kg
Max. noise emission
14,21
- free-standing, measured from 1m 48,1dB(A) 50dB(A)
- built-in
22
, measured from 1m 37,0dB(A) 38dB(A)
Housing material and colour coated steel sheet (1.5mm), pigeon-blue (RAL5014)
9.2 Dimensions
EBC10
With 0.5l bottle (default) With 2.0l bottle (option)
Width (mm)
EBC 378,50 378,50 EBC
Edge dist. (right) includ. silicone pipe & cable (left) 50,00 50,00 Edge dist. (right) includ. silicone pipe & cable (left)
Total=Required space with bottle on the front 428,50 428,50 Total=Required space with bottle on the front
Bottle with sensor holder & belt (left) 83,00 115,00 Bottle with sensor holder & belt (left)
Total=Required space with bottle on the left 511,50 543,50 Total=Required space with bottle on the left
Height (mm)
EBC 133,50 133,50 EBC
Edge distance (top) 50,00 50,00 Edge distance (top)
Required space 183,50 183,50 Total without bottle
Bottle (apart; highest point) 138,00 215,00 Bottle (apart; highest point)
Space for silicone pipe (top) 5,00 5,00 Space for silicone pipe (top)
Total with bottle, without required edge distance 143,00 220,00 Required space
Depth (mm)
EBC (includ. hosepipe fittings & screws) 233,00 233,00 EBC (includ. hosepipe fittings & screws)
Space for hosepipes (back), plugs & cables (front)
23
106,00 106,00 Space for hosepipes (back), plugs & cables (front)
23
14
Approximately.
15
Condensed/evaporated water in grammes per hour. Used build up for the tests: EBCs with respective standard accessories and standard lengths for the hosepipes.
16
The actual setpoint range in a given specific situation can be both bigger and smaller, as it depends on a variety of further variables - additionally to the ambient conditions (such
as the kind of materials stored in the case or the quality of the case sealing etc).
17
At typical installations using the hosepipe lengths that are usually delivered (3m/5m/6m) and without any other accessories that may have an impact on the airflow, like air filters
FLT.
18
Applies to the conditions generally obligatory for operation or damage-free storage, but not to the conditions were the full capacity with respect to the achievable setpoint range
is given.
19
The tolerance rises with the chosen setpoint.
20
Has to be fuse-protected and earthed.
21
Disregarding the noise during the pump processes (sporadic occurrences). The values were measured on units with standard fans and during the dehumidification process
(increased noise emission through the work of the cooling air fan(s)). The units remain almost noiseless when humidifying (except device cooling becomes necessary) or once
the setpoint has been reached.
22
In the plinth of a wooden showcase with air slots, without sound insulation.
23
Additional space might be required for the plug of an RS232 cable, where applicable.
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 24.11.2014. Subject
to modification.
