Mircom 9500 Series User Manual

MIRCOM TECHNOLOGIES LIMITED, 9500 Series: No Subscriber Line Page 47
SET CLOCK (NOT AVAILABLE DO NOT USE)
To set the clock, scroll through until you reach the feature as shown below.
Set Time-of Day
Clock -Press #
Press # to access the feature. The display should appear...
Hr Mn Sc
_ _ : _ _ : _ _ <----Hour : Minute : Second
Enter the Time-of-Day. To quit, enter *000 while at PROGRAM MODE menu to return to NORMAL MODE.
TWO 11-DIGIT TELEPHONE NUMBER ENTRY(9501A only)
The system has a built-in Dedicated Telephone Jack that can be connected to a standard residential jacks (RJ-
11/CA-11). The user can program two of up to 11-digit telephone numbers that can be auto-dial through the
telephone network. Each telephone number has its own dial code. To take advantage of this unique feature, a
touch tone (DTMF) line is required.
To enter the FIRST 11-digit telephone number, scroll through until you reach the feature as shown below.
Set 1st 11-digit
Number - Press #
Press # to access the feature. The display should appear...
(1) Code: _ _ _ _
_ - _ _ _ - _ _ _ - _ _ _ _ <----up to 11 digits telephone number
Enter Dial Code and telephone number. If less than 11 digits are required, simply press # to blank the remaining
digit(s). When you make a mistake and wish to re-enter the code, press * to enter code again. After entering the
telephone number, the display should appear...
* = Abort, # = Store
x - x x x - x x x - x x x x
Press * to abort or # to store entry. To quit, enter *000 while at PROGRAM MODE menu to return to NORMAL
MODE. To program the second 11-digit number, scroll through until you reach the menu for entering the 2nd 11-
digit telephone number and follow the above process.
RING PATTERN SELECT (9501A only)
The system allows the user to adjust the ringing pattern as required. Factory default is set to a distinct ringing
pattern. Normal or Standard North American ringing pattern can be selected for applications where ringing pattern
is critical; especially for older answering machines that only accept normal ringing pattern.
To change the ringing pattern, scroll through until you reach the feature as shown below.
Program ringing
pattern - Press #
Press # to access the feature. The display should appear...
Distinct/Normal
D=15 N=38 _ _ <---- 38 for North American ringing pattern
Enter 15 for Mircom's distinct ringing pattern or 38 for Normal or Standard North American ringing pattern. Enter
any number for other desired ringing pattern. After entering the selection, the display should appear...
* = Abort, # = Store
D=15 N=38 x x
Press * to abort or # to store entry. To quit, enter *000 while at PROGRAM MODE menu to return to NORMAL
MODE.
