MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 41
Enter the New Master Code. Please do not use *888 for Master Code. The next display should appear...
#=Store, *=Abort
* x x x
Press # to store or * to abort entry. After pressing the store button, the next display should appear...
Press *
To exit
Press * to exit to PROGRAM MODE menu. To quit, enter *000 while at PROGRAM MODE menu to
return to NORMAL MODE.
NOTE: To restore Master Code, please refer to FIG. 12 for location of reset pads.
SELECT “DOOR OPEN CODE” FOR MAIN AND AUXILIARY DOORS (DTMF only)
This feature will allow the user to change the Door Open Code (DTMF only) to any desired code from 0 to 9. This
feature is particularly useful when the default Code for opening the Main or Auxiliary doors are false-triggering the
door strike “open” due to a “series of tones” produced by some older answering machines when it answers a call. It
is recommended to select a stable Door Open Code when a similar type of problem occurs to improve security.
These “Door Open Codes” are used by all Residents to release the door by simply dialling the assigned code on their
telephone while on-line with their visitors.
NOTE: The Door Open Code for pulse (rotary) type telephones is fixed at “9". Dialling a pulse digit “9" will activate
the main door relay. An auxiliary door relay can be activated only by a standard DTMF Code as
programmed; there is no provision for pulse activation.
TO CHANGE THE DOOR OPEN CODE FOR MAIN DOOR:
Scroll though until you reach the feature as shown below.
To Change DTMF
Code#1 - Press #
Press # to access the feature. The next display screen should appear...
Enter DTMF digit
to open door ( _ ) Digit “9" is the factory default.
Enter a number from 0 to 9 for code to open the main door. The next display screen should appear...
#=Store, *=Abort
to open door ( x )
Press # to store or * to abort entry.
To quit, enter *000 while at PROGRAM MODE menu to return to NORMAL MODE.
