MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 7
NON-SCROLLING DIRECTORY CONTROLLERS:
Model ADC-0040A ± Autodialer Telephone Access Controller, 40 Residents capacity.
Model ADC-0120A ± Autodialer Telephone Access Controller, 120 Residents capacity.
Model ADC-0360A ± Autodialer Telephone Access Controller, 360 Residents capacity.
Model ADC-0960A ± Autodialer Telephone Access Controller, 960 Residents capacity.
Note: Please see page 4 for System Block Diagram for more information.
3. SYSTEM & DOOR RELEASE POWER REQUIREMENTS
A single Mircom's PS-3B (Tri-Volt) power transformer is required to power the unit and lamps. A second power
transformer is required to operate the door release. Please note that the transformer and the door release must be
compatible. When using Mircom's M-10 door strike, a compatible PS-3B power transformer with 8VAC tapped is used
to power the door strike. If using an equivalent door release, the maximum strike load that may be switched through
the control unit is 28 VAC or DC, 3 Amp. maximum.
Below are the available power supplies and door strikes:
Model PS-2 ± 16 VAC / 20 VA, CSA approved Class 2 Power Transformer.
Model PS-4 ± 16 VAC / 40 VA, CSA approved Class 2 Power Transformer.
Model PS-3B ± 8 VAC /13 VA, 16 VAC /17 VA, 24 VAC /20 VA, CSA approved
Class 2 Power Transformer.
Model SPS-600W ± 600 Watts Standby Battery Supply.
Model M-10 ± DC (silent) or AC (buzzing) Door Strike. Use PS-3B transformer.
Model M-10HD ± AC (buzzing) Heavy Duty Door Strike. Use PS-3B transformer.
Model M-20 ± DC (silent) or AC (buzzing) Heavy Duty Door Strike. Use PS-3B transformer.
Important note: The door strike must have its own separate power transformer. Do not tap or use the
system power transformer.
Notes: Please see appendix "A", page 43 for specifications.
Please see page 4 for System Block Diagram for more information.
4. SITE SELECTION
Install the Entry Panel as near as possible to the controlled entry point. Do not install the system to a location where
the LCD display is exposed to direct sunlight since it will degrade the visibility.
5. TELEPHONE LINE
A Pulse (rotary) or Touch-Tone (DTMF) dedicated telephone line is required for single or multiple entrances
configuration. If possible, have the jack installed inside the control unit enclosure. Provide the following information
to phone company when ordering a telephone line:
Industry Canada (formerly D.O.C.) Registration Number: 1156 6662 A
F.C.C. Registration Number: 1M8CAN-22412-OT-E
6. WIRING REQUIREMENTS
Count the number of wires and identify the proper gauges that are required for your system configuration. For typical
Single or Multiple entrances applications, please refer to page 4 for System Block Diagram. For custom applications,
we recommend to consult our Engineering Field Support Personnel for evaluation.
7. POST OFFICE LOCK
The system has a built-in micro switch and mounting hardware for postal lock installation. If a postal service is
required, contact the Post Office to obtain the lock.
