MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 5
PRE-INSTALLATION PLANNING
Before the actual installation begins, the system requires various items to be prearranged and are described below:
1. ENTRY OR LOBBY PANEL TYPES
The UNIVERSAL series entry/lobby panels are hooded surface mount enclosures with built-in lighting for outdoor
or indoor applications. Optional flush trim rings are available for semi-flush installations. There are eight (8) models
available and are listed below:
Universal Panels for Scrolling Directory:
Model MUS-5000SV ± Stainless Steel finish entry panel comes with keypad, 4x20 VFD
display, microphone, speaker, and micro switch for postal lock. No
controller.
Model MUS-5000SHV ± Stainless Steel finish entry panel comes with keypad, 4x20 VFD
display, armoured handset, and micro switch for postal lock. No
controller.
Universal Panels for Non-Scrolling Directory:
Model MUS-5000 ± Stainless Steel finish entry panel comes with keypad, 2x16 LCD
display, microphone, speaker, and micro switch for postal lock. No
directory and controller.
Model MUS-5000H ± Stainless Steel finish entry panel comes with keypad, 2x16 LCD
display, handset, and micro switch for postal lock. No directory and
controller.
Model MUS-5024 ± Stainless Steel finish entry panel comes with keypad, 2x16 LCD
display, microphone, speaker, micro switch for postal lock, and paper
directory for 24 names. No controller.
Model MUS-5120 ± Stainless Steel finish entry panel comes with keypad, 2x16 LCD
display, microphone, speaker, micro switch for postal lock, and paper
directory for 120 names. No controller.
Model MUS-5120H ± Stainless Steel finish entry panel comes with keypad, 2x16 LCD
display, handset, micro switch for postal lock and paper directory for
120 names. No controller.
Model MUS-5120V ± Stainless Steel finish Vertical (slim) entry panel comes with keypad,
2x16 LCD display, microphone, speaker, micro switch for postal lock,
and paper directory for 120 names. No controller.
Accessories:
Model MUFT-5000P ± Flush trim ring for MUS-5000/H/S/SH and MUS-5024 panels. Painted
black (textured).
Model MUFT-5120P ± Flush trim ring for MUS-5120/H, and MPD-5240 panels. Painted
black (textured).
Model MUFT-5120VP ± Flush trim ring for MUS-5120V panel. Painted black (textured).
Model MPD-5120 ± Stainless Steel add-on paper directory panel, 120 names capacity.
Model MPD-5240 ± Stainless Steel add-on paper directory panel, 240 names capacity.
Model MLK-040 ± Magnetic strips directory kit, 40 names capacity. It comes with plastic
letters, magnetic strips, brackets, and hexnuts.
Model TH-101 ± Thermostat heater.
Note: Painted Silver, Gold & Copper Vein lobby panels are available by custom order.
