(SURFACE)
SIDE VIEW
(FLUSH)
SIDE VIEW
BOTTOM VIEW
(SURFACE)
BOTTOM VIEW
(FLUSH)
5 15/16"
2"
1 5/16"
1"
1"
BACKBOX (SURFACE)
BBS-6003
WIDTH
13 11/16"
HEIGHT
15 9/16"
DEPTH
2 3/16"
13 13/16"
HEIGHT
BACKBOX (FLUSH)
BBF-6001
11 1/4"
WIDTH
2 3/16"
DEPTH
BACKBOX
BACKBOX
FIG. 3: SCROLLING DIRECTORY PANELS
DOOR FRAME FOR
MCS-6001S , MCS-6001SH
MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 12
MOUNTING THE CONTINENTAL TYPE LOBBY/ENTRY PANEL
Mount the panels as shown in FIG.3 (for scrolling) or FIG.3A (for non-scrolling) using the supplied screws.
