Mircom QX-mini Programming Guide

92
QAS-2X8 Splitter Configuration - QX-mini and FX-3500 - Two Stage
Table 1 FX-3500 Output Modules Example
Address
in
FX-3500
Address
in
QX-mini
Device Type Tag Alarm
Correlations
Status
Correlations
201 101 Relay Output Module
(CLIP)
Relay
QX-mini
Signal Silence
Signal Silence
202 102
Input Module (CLIP)
Trouble
Input
QX-mini AC
Power Fail
203 103
Input Module (CLIP)
Building/
Property
Safety
QX-mini
Paging Active
204 104
Input Module (CLIP)
Trouble
Input
QX-mini
Common
Trouble
205 105
Input Module (CLIP)
Trouble
Input
QX-mini
Battery
Trouble
206 106
Input Module (CLIP)
Trouble
Input
QX-mini
Ground Fault
Trouble
281 181 Supervised Output
Module (CLIP)
Signal Floor 1 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
282 182 Supervised Output
Module (CLIP)
Signal Floor 2 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
283 183 Supervised Output
Module (CLIP)
Signal Floor 3 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
284 184 Supervised Output
Module (CLIP)
Signal Floor 4 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
285 185 Supervised Output
Module (CLIP)
Signal Floor 5 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
286 186 Supervised Output
Module (CLIP)
Signal Floor 6 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
287 187 Supervised Output
Module (CLIP)
Signal Floor 7 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
288 188 Supervised Output
Module (CLIP)
Signal Floor 8 Alert
Detectors on
floors 1 to 8
Fire Drill, Total
Evacuation
291 191 Relay Output Module
(CLIP)
Relay Floor 1 Evac
Detectors on
floors 1 and 2
Tota l
Evacuation
292 192
Relay Output Module
(CLIP)
Relay Floor 2 Evac
Detectors on
floors 1, 2 and
3
Tota l
Evacuation
