Mitel 6865i SIP Phone Release 4.1.0 User Guide
PHONE LOCK KEY
You can configure a programmable key on the phone to use as a lock/unlock key. You assign
the function of the key as Phone Lock.
CONFIGURING A PHONE LOCK KEY
1. Click on Operation > Programmable Keys.
or
Click on Operation > Expansion Module <N>.
Programmable Keys
2. Select from Key 1 through Key 8.
3. In the Type field, select Phone Lock.
4. Click Save Settings.
Expansion Module Keys
5. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
6. In the Type field, select Phone Lock from the list of options.
7. Click Save Settings.
MITEL WEB UI
Note: ou can lock/unlock the phone using the new key you just configured, using the
Mitel Web UI at the path Operation > PhoneLock, or using the Phone Lock option on the
IP phone UI at the path Options > Phone Lock. For more information about using the
lock/unlock feature, see “Locking/Unlocking a Phone” on page 54.
