Mitel 6865i - PHONE LOCK

Mitel 6865i SIP Phone Release 4.1.0 User Guide
52
CREDENTIALS
Some features (e.g. LDAP Directory, Microsoft Exchange Directory, BroadSoft XSI features,
etc...) require authentication to external servers before they can be used. The Credentials
options menu allows you to enter in your user credentials for these respective features.
ENTERING USERNAMES/PASSWORDS AND CONNECTION TESTING
USING THE IP PHONE UI
1. Press on the phone to enter the Options List.
2. Select Credentials.
3. Use the 5 and 2 keys to navigate to the desired feature and select 4 Enter.
4. Press the 2 key to navigate to the Enter Username screen and select 4 Enter.
5. Using the dialpad keys, enter in your username and select 4 Set.
6. Press the 2 key to navigate to the Enter Password screen and select 4 Enter.
7. Using the dialpad keys, enter in your password and press the button or select 4 Set.
DIRECTORY
You can configure directory entries to display using the contact’s first name and then last name
or vice versa. Moreover, the option to sort contacts using either their first name or last name is
available. If external Directory sources are configured, you can enable/disable the respective
Directory sources as well as rename Directory folder labels in this menu.
CONFIGURING DIRECTORY DISPLAY AND SORTING OPTIONS USING
THE IP PHONE UI
1. Press on the phone to enter the Options List.
2. Select Directory.
Note: Menu available only if certain features requiring authentication to a server have
been configured by your Administrator.
IP PHONE UI
Note: The 3 key can be used to perform a backspace.
Note: The 3 key can be used to perform a backspace.
Note: For more information on Directory functionality, see “Directory” on page 127.
IP PHONE UI
