Line Keys and Programmable Keys
FLASH KEY
You can set a programmable key to generate a flash event when it is pressed on the 6865i.
You do this by setting the key to Flash. The IP phone generates flash events only when a call
is connected and there is an active RTP stream (for example, when the call is not on hold).
CONFIGURING A FLASH KEY
1. Click on Operation > Programmable Keys.
or
Click on Operation > Expansion Module <N>.
Programmable Keys
2. Select from Key 1 through Key 8.
3. In the Type field, select Flash.
4. Click Save Settings.
Expansion Module Keys
5. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
6. In the Type field, select Flash.
7. Click Save Settings.
MITEL WEB UI
