Technical specifications and Compliance to Regulations and Standards
77
MITEL 732D
Note that the metric system is used in Canada, while Imperial measurements are used in the USA.
OVERVIEW
Dimensions (l × w × d): 152 x 62 x 25 mm (excl. clip) (6 x 2.4 x 1 × 2.2 × 0.9 in)
Weight: 185 g (incl. clip) (6.5 oz) EX 190g (6.7oz)
Material: Case: PC, Key pad: coated vulcanized silicone, Clip: PA
Color: Black
Display: TFT-Colour display (2,4“, 220 x 320 dots, 65536 colours)
Clip: Hinge-type
BATTERY AND CHARGING
Type: Li-Ion 3.7 V 920 mAh
CONNECTORS
Multi-purpose connector: With USB-C for fast software download, configuration and battery
charging
Headset connector: Standard 3.5 mm
AUDIO
Ring signal: Maximum sound level 88 dBA SPL @ 10 cm
Earpiece: Adjustable in 10 steps of 3dB each
Loudspeaker: Duplex loudspeaking function
Voice Codecs: G.722, G.726
BLUETOOTH
Bluetooth radio spectrum: ISM 2.4000-2.4835 GHz
Output power: Class 2, maximum 3 dBm
Bluetooth Compliance: European Union: EN 300328, EN 301489-17
Australian and New Zealand: EN 300328, EN 301489-17,
AUS/NZS-4771
RADIO
Frequency range: 1880-1900 MHz: Europe, Africa, Middle East, Australia, New
Zealand and parts of Asia
1920-1930 MHz: US
1910–1906 MHz: Thailand
1910–1920 MHz: Brazil and Latin America
Modulation: GFSK
Channel spacing: 1.728 MHz
Antenna: Integral
Sensitivity: -93 dBm
Maximum average power: EU/LA/BR: 20 mW(G722 double slot)
US: 8 mW (G722 double slot)
ENVIRONMENTAL
Operating temperature: -5°C to +45°C
