Mitel 700 - Mitel 742 D

Mitel 700 DECT Phone User Guide
80
MITEL 742D
Note that the metric system is used in Canada, while Imperial measurements are used in the USA.
OVERVIEW
Dimensions (l × w × d): 152 x 62 x 25 mm (excl. clip) (6 x 2.4 x 1 × 2.2 × 0.9 in)
Weight: 185 g (incl. clip) (6.5 oz) EX 190g (6.7oz)
Material: Case: PC, Key pad: coated vulcanized silicone, Clip: PA
Color: Black
Display: TFT-Colour display (2,4“, 220 x 320 dots, 65536 colours)
Clip: Hinge-type
BATTERY AND CHARGING
Type: Li-Ion 3.7 V 920 mAh
CONNECTORS
Multi-purpose connector: With USB-C for fast software download, configuration and battery
charging
USB-C charging port to support the new EU regulations
Headset connector: Standard 3.5 mm
AUDIO
Ring signal: Maximum sound level 88 dBA SPL @ 10 cm
Earpiece: Adjustable in 10 steps of 3dB each
Loudspeaker: Duplex loudspeaking function
Voice Codecs: G.722, G.726
BLUETOOTH
Bluetooth radio spectrum: ISM 2.4000-2.4835 GHz
Output power: Class 2, maximum 3 dBm
Bluetooth Compliance: European Union: EN 300328, EN 301489-17
Australian and New Zealand: EN 300328, EN 301489-17,
AUS/NZS-4771
RADIO
Frequency range: 1880-1900 MHz: Europe, Africa, Middle East, Australia, New
Zealand and parts of Asia
1920-1930 MHz: US
1910–1906 MHz: Thailand
1910–1920 MHz: Brazil and Latin America
Modulation: GFSK
Channel spacing: 1.728 MHz
Antenna: Integral
Sensitivity: -93 dBm
Maximum average power: EU/LA/BR: 20 mW(G722 double slot)
US: 8 mW (G722 double slot)
ENVIRONMENTAL
Operating temperature: -5°C to +45°C
