2 - 43
2 SYSTEM CONFIGURATION
(11) Forced stop input connector
The pins layout (from front view) and connection of the forced stop input
connector is shown below.
3
1
2
Pin No. Signal name
3 EMI.COM
2
No connect
(Note-1)
1 EMI
(Note-1): Do not connect anything to the terminals
listed as "No connect".
• Applicable connector model name
FK-MCP1.5/3-ST-3.81 connector (PHOENIX CONTACT make) (Attachment)
• Conductor size for power line
0.3 to 1.5mm
2
(AWG16 to AWG22)
To Next Page
