13 - 9 13 - 9
MELSEC-Q
13 TROUBLESHOOTING
Error
code
Error name Error Operation status at error occurrence
910
Setting range outside OPR
method
The setting value of "
OPR. 1
OPR method" is outside
the setting range.
911
Setting range outside OPR
direction
The setting value of "
OPR. 2
OPR direction" is
outside the setting range.
913
Setting range outside OPR
speed
•
The setting value of "
OPR. 4
OPR speed" is outside
the setting range.
•
The setting value of "
OPR. 4
OPR speed" is lower
than "
Pr. 6
Bias speed at start".
•
The setting value of "
OPR. 4
OPR speed" is higher
than "
Pr. 5
Speed limit value".
914
Setting range outside creep
speed
•
The setting value of "
OPR. 5
Creep speed" is
outside the setting range.
•
The setting value of "
OPR. 5
Creep speed" is higher
than "
OPR. 4
OPR speed".
•
The setting value of "
OPR. 5
Creep speed" is lower
than "
Pr. 6
Bias speed at start".
915
Setting range outside
ACC/DEC time at OPR
The setting value of "
OPR. 6
ACC/DEC time at OPR"
is outside the setting range.
916
Setting range outside
DEC/STOP time at OPR
The setting value of "
OPR. 7
DEC/STOP time at
OPR" is outside the setting range.
917
Setting range outside
setting for the movement
amount after near-point dog
ON
The setting value of "
OPR. 8
Setting for the
movement amount after near-point dog ON" is outside
the setting range.
918
Setting range outside stop
mode during path control
The setting value of "
Pr. 10
Stop mode during path
control" is outside the setting range.
The module READY signal (X0) does not turn
ON.
