IPB-5000A
11. Specifications
11-4
IPB-5000A-00-00/03 IPB-5000A-00-01/02/04/05
Weld Power
Supply
Three-phase, 200 to 240VAC
(50 Hz / 60 Hz)
(Voltage cannot be selected.
Fixed to a customer-specified
voltage in factory shipment.)
Three-phase, 380 to 480VAC
(50 Hz / 60 Hz)
(Voltage cannot be selected.
Fixed to a customer-specified
voltage in factory shipment.)
IPB-5000A-00-00/01/03/04 IPB-5000A-00-02/05
CE Marking
Noncompliant
Compliant
(See “EC Declaration of Conformity”.)
IPB-5000A-00-00/01/03/04 IPB-5000A-00-02/05
Outline (mm)
269 (H) x 172 (W) x 390 (D)
(No projections included)
349 (H) x 172 (W) x 390 (D)
(No projections included)
Mass (kg)
15 19
IPB-5000A-00-03/04/05
Displacement
Measurement
Range
30.000mm Max.
Displacement
Measurement
Accuracy
+/-15µm
Displacement
Sensor
(Option)
GS-1630A manufactured by Ono Sokki Co. Ltd.
GS-1613A manufactured by Ono Sokki Co. Ltd.
LGK-110* manufactured by Mitsutoyo Corp.
ST1278* manufactured by HAIDENHAIN
* An optional conversion cable is necessary.
Displacement
Monitor
Setting
Range
Upper/Lower Limit Setting Range of Final Displacement:
-29.999mm to +29.999mm (0.001mm ea.)
Delay Time: 0 to 999ms
Workpiece
Detection
At the end of Squeeze, the displacement is checked to confirm
whether or not a workpiece is set.
Upper/Lower Limit Setting Range of workpiece detection:
-29.999mm to +29.999mm (0.001mm ea.)
Weld Stop
When WE1 or WE2 reaches the designated value of
Displacement, WE1 moves to CO and WE2, to HO.
Displacement Setting Range of Weld Stop: -29.999mm to
+29.999mm (0.001mm ea.)
Envelope
Possible to set Upper/Lower Limit Setting to Displacement
waveform
