. Keypad: complete illuminated keypad with 19 tactile keys with
4 arrow keys.
. Memory: FlashRom technology guaranteeing the safeguard of navigation information,
waypoints, routes etc., backup lasts up to 100 years no lithium battery
. Dimensions of the receiver: 198 x 101 x 63 mm.
. Dimensions of antenna: 113 x 75
mm + whip antenna (0.85 m) for the FX412.
. Operating temperature:
-
10°C to +60°C.
. Storage temperature:
-
20°C to + 70°C.
. Power supply: 10 to 36 volts DC.
. Waterproof: IPX6 IEC 529 norm
FX312
FX412
. Weight
400 grams
450 grams
. Consumption w/o backlight
1.5 watts
2.4 watts
. Consumption with backlight
2.0 watts
3.0 watts
. Electromagnetic compatibility: According to the IEC norm 945 second and third publication.
. Data input and data output :
. Serial output : 1 RS422 + 1 RS232 ; format NMEA180, NMEA182, NMEA183 V1.5,
NMEA183 V2.0, MLR, WPTS & RTES, CHART OUTLINE, TRACK.
. Serial input : 1 RS232 ; format NMEA183, RTCM104.
* * ATTENTION: Do not expose to direct sunlight.
4 –
PARTICULAR SPECIFICATIONS OF THE FX412
DGPS FX412 specifications
. RTCM SC 104 V2.1 receiver.
. Frequencies : 281.5 to 325 KHz by step of 500 Hz,
Europe, Asian, Oceania and US range.
. Baud rate : 100 Bps and 200 Bps.
. Manual selection of the stations.
. Type : dual super heterodyne with MSK coherent detection.
. Adja
cent channel rejection +/
-
500 Hz = 30 dB.
. central channel rejection +/-
10 Hz =
-3 dB.
