Caution
Only use to connect the camera. Standard cables purchased
from other suppliers do not meet the necessary specifications for proper protection
(no longer weatherproof according to IP66).
Insert the cable into the receptacle on the camera. Position the bayonet catch from the
side (opening points to the right). Rotate the bayonet catch clockwise to the "filled circle"
symbol (see diagram). The cable is now properly retained.
Mini USB cable
Close the cable
retainer by rotating
the bayonet catch to
the marked position
MOBOTIX patch cables
are available as accesso-
ries in different lengths
(1 m, 2 m, 5 m and 10 m)
Bayonet catch
closed
