Section 5 --- Equipment
Cayman 2005
178
AWNINGS
Slide-out Cover
The slide-out cover is automatic. When the slide-out moves in or out, the cover reacts to the slide-out
direction. A fixed edge of the slide-out cover is installed into an awning rail, mounted just above the
slide-out. A spring-loaded roller with special brackets mounts to the slide-out. In a hard rain, the cover
helps prevent water from penetrating the seal of the slide-out.
The slide-out cover will extend automatically attaining full coverage when the slide-out achieves
maximum extension.
NOTE:
Water may pool on top of the extended cover. As the slide-out is retracted, the water
is removed when the cover retracts. Retract room slowly. Pause three or four times
to allow any accumulated water a chance to run off.
The slide-out cover retracts automatically and rolls up to the travel position when the slide-out is
completely closed.
NOTE:
When retracting the slide-out, stop the room approximately halfway. Confirm that
the fabric is rolling properly before fully retracting the slide-out.
030924b
