Equipment --- Section 5
Cayman 2005
189
SLIDING DOOR
The sliding pocket door uses two
rollers at the top of each door. During the
life of the motorhome the sliding door may
need adjusting. The sliding pocket door
can be adjusted to close tight against the
wall. Use a small wrench and turn the
adjusting screw upward or downward.
If, for any reason, the pocket door
needs to be removed, locate the portion
that is secured to the top of the pocket
door and rotate the small lever outward to
release the latches.
LUBE:
The pocket door rollers should be lubed with just a small drop of oil once a year to
help increase the life of the rollers and improve the sliding of the door.
REAR LADDER (Optional)
The rear ladder allows access to the roof. Care should be used when climbing the ladder. Access to
the roof should be limited to cleaning and sealing purposes only. The lower portion of the ladder is
removable and stored in the cargo bay.
NOTE:
Maximum weight is 300 lbs.
070147b
