Printing a Test Label
1. From the Diagnostics Menu, press or until you see
DIAGNOSTICS
User Diag
2. Press Enter/Pause and until you see
USER DIAG
Test Label
3. Press Enter/Pause. The following test labels print.
The first label shows the printer's configuration by packet (A-G). The second
label shows the model number, software version, stock count, voltage, print
contrast, printhead resistance, number of bad dots, and installed options.
The test label also shows an inch count for the high energy ribbon. This
information will help Technical Support diagnose the problem. Refer to the
optional Packet Reference Manual for more information about the test label.
You can also print a test label by pressing and at the same time. Hold
for one second and release. If test labels do not print, call Technical
Support.
10-2 Operator's Handbook
