Setting the Baud Rate
To change the setting, from the Main Menu select Setup, Port Settings, then
Serial Comm. If password protection in enabled, press Feed/Cut three
times, then press Enter/Pause before you see the Setup Menu options.
Then, follow these steps.
1. Press or until you see
SERIAL COMM
Baud Rate
2. Press Enter/Pause. The current setting is displayed, for example:
BAUD RATE
9600
Press or to display the baud rate you need, then press Enter/Pause.
Press Escape/Clear until you see the Main Menu.
Setting the Word Length
To change the setting, from the Main Menu select Setup, Port Settings, then
Serial Comm. Then, follow these steps.
1. Press or until you see
SERIAL COMM
Word Length
2. Press Enter/Pause. The current setting is displayed, for example:
WORD LENGTH
8
3. Press or to display the word length you need, then press
Enter/Pause. Press Escape/Clear until you see the Main Menu.
5-2 Operator's Handbook
