Monarch 9855 - Linerless Supplies; String Tag Supplies

Linerless Supplies
For Supply Width
greater than or equal to
Use Supply Length
1.5 inches (38 mm) 1.5 inches to 16 inches (38 mm to 406 mm)
2.0 inches (51 mm) 1.5 inches to 16 inches (38 mm to 406 mm)
3.0 inches (76 mm) 2.0 inches to 16 inches (51 mm to 406 mm)
4.0 inches (102 mm) 2.5 inches to 16 inches (64 mm to 406 mm)
Note: A 0.50 inch non-print zone exists on the leading edge (beginning) of
all labels.
String Tag Supplies
Widths: 0.90 inches (23 mm) minimum
2.0 inches (51 mm) maximum
Lengths: 0.78 inch (20 mm) minimum
1.78 inches (45 mm) maximum
Thickness: 5.5 to 16 mils
String Loop Length: 1.5 inches (38 mm) maximum
String Orientation: Facing operator
Wind Direction: Face out
Max. Roll Diameter: 9.375 inches (238 mm)
Supply Core: 3.0 inches (76 mm) or 4.0 inches (102 mm)
4.0 inches is recommended.
A-4 Operator's Handbook
