Supplies
For high temperature or high humidity environments, contact us for supply
recommendations. Continuous (non-indexed) supply does not have
perforations or black marks and must be used in continuous mode. We
recommend using continuous supply with a tear bar or the optional knife. If
you purchased the optional knife, you cannot use the tear bar. Aperture
supplies are tags or labels with holes (or openings) in them. The supply is
sensed using the holes. The holes can be only on the edge or in the center
of the supply.
Edge Aperture Center Aperture
Sup
ply Types: Thermal Transfer or Direct
Supply Widths: 0.75 inches (19 mm) minimum
4.25 inches (108 mm) maximum
Supply Lengths: 0.32 inch (8 mm) minimum
0.75 inch (19 mm) minimum for tags
1.2 inches (30 mm) minimum for cutting tags
17.5 inches (445 mm) maximum
Total Thickness: 7to 12 mils
7 to 10 mils with the optional knife
Specifcations A-3
