Monarch 9855 - Loading Labels or Tags

Loading Labels or Tags
Make sure the printer is configured for the correct supply type.
1. Open the cover.
2. Unlo
ck the printhead by turning the retaining latch.
3. Lift printhead assembly using the printhead tab until the assembly locks
into place.
Deflector Tab
Printhead Tab
2-2 Operator's Handbook
