4-22 Operator's Handbook
Enabling the Verifier
The verifier scans and checks the quality of bar codes as they are printed.
The optional verifier must be purchased separately. The verifier scans
parallel bar codes; it cannot scan serial bar codes.
The verifier must be enabled and set up before you can scan bar codes.
For additional set up procedures, refer to your verifier's Operating
Instructions for more information.
To enable the verifier, from the Main Menu, select Setup, then Verifier.
Then follow these steps.
1. Press or until you see
VERIFIER
State
2. Press Enter/Pause. The current setting is displayed, for example:
VERIFIER
Disabled
3. Press or to see the other option. After you display the option you
want, press Enter/Pause. Press Escape/Clear until you see the Main
Menu.
