6. Remove the new ribbon from the package as shown. Do not wrinkle or
crush the new ribbon.
7. Slid
e the ribbon onto the back reel as far as it will go. The ribbon roll
only fits on the reel one way. Carefully unwind a few inches of ribbon
from the bottom of the roll.
Note: Make sure the “Monarch This End Out” writing is facing out.
The ribbon only fits on the reel one way.
8. Carefully feed the ribbon under both ribbon rollers and printhead as
shown.
9. Align the ribbon and make sure it is straight and centered throughout the
path.
10. Tape the ribbon to the take-up core. Do not tape the ribbon to the
take-up reel.
11. Rotate the take-up core until the leader is past the printhead.
Take-up Reel
Ribbon Rollers
Take-up Core
Loading Ribbon 3-3
