The options are listed in the table below.
Option Choices Default
Supply Type
Aperture/Die Cut/Black
Mark/Continuous
Die Cut
Ribbon No/Yes/High Energy Yes
Speed 2.5/4.0/6.0/8.0/10.0/12.0/Default Default
Feed Mode Continuous/On-Demand Continuous
Backfeed Off/On/Extended Off
Print Position -450 to 450 0
Supply Position -300 to 300 0
Margin Position -99 to 99 0
Cut Position -300 to 300 0
Dispense
Position
50 to 200 65
Backfeed
Distance
10 to 200 65
Separators No/Yes/Long No
Skip Index No/Yes No
Knife Control -20 to 20 0
Error Action
Normal
Overstrike/Continue x1
Overstrike/Continue x2
Overstrike/Continue x3
Overstrike/Continue x4
Overstrike/Continue x5
Normal
Contrast -699 to 699 0
To exit an option without changing the setting, press Escape/Clear.
4-2 Operator's Handbook
