7 Description of Function Codes NICE5000 User Manual
- 194 -
LED
No.
Seg-
ment
FU-27 Car output
state
FU-28 Hall sate
FU-29 System state
1
FU-30 System state
2
No.
Signal
No.
Signal
No.
Signal
No.
Signal
1
A 0
Lamp/Fan
running
0
Reserved
0
Door open 1
button
0
Up direction
display
B 1
Door 1 open
1
Elevator lock
signal
1
Door close
1 button
1
Down direction
display
C 2
Door 1 close
2
Fire
emergency
signal
2
Door open
delay 1
2
Running state
D 3
Forced door
close 1
3
Current oor
forbidden
3
Direct travel
ride switch
3
System full-load
E 4
Door 2 open
4
VIP signal
4
Attendant
switch
4
System
overload
F 5
Door 2 close
5
Security
signal
5
Direction
change
switch
5
System half-
load
G 6
Forced door
close 2
6
Service oor
switchover
6
Independent
running
switch
6
System light-
load
DP 7
Up arrival gong
7
Parking oor
switchover
7
Fire
emergency
2 switch
7
Commissioning
valid
2
A 8
Down arrival
gong
8
Down
collective
selective
switch
8
Door open 2
button
8
Maintenance
valid
B 9
Reserved
9
Peak service
switch
9
Door close
2 button
9
Peak service
enabled
C 10
Reserved
10
Fire
emergency
oor
switchover
10
Door open
delay 2
10
Reserved
D 11
Reserved
11
Reserved
11
Reserved
11
Reserved
E 12 12 12 12
F 13 13 13 13
G 14 14 14 14
DP 15 15 15 15
Function Code Parameter Name Setting Range Default Unit Property
FU-31 Car load 0–255 0 - ●
It displays the current car load.
