Motorola APX E5

• If the user name is invalid, login fails and the user login failure indicator (IP indicator) icon blinks.
The display also shows Login failed.
• If the PIN is invalid, login fails and the user login failure indicator (IP indicator) icon blinks. The
display also shows Login failed.
• Wait for the logged in confirmation screen. If the login process is successful, the display shows the
successful user login indicator (IP indicator) icon and Logged in, with Logt and Exit.
NOTE: To cancel the login process and return to the initial user login screen, press the Menu
Select button directly below Cncl.
6.14.2.2
Logging Out
Prerequisites:Once the data application registration is completed, you can log out.
When and where to use:
NOTE: Private data refers to all messages in the text messaging Inbox, Draft, and Sent folder.
The next user is able to access the Inbox, Draft, and Sent messages if private data is not
deleted.
Procedure:
1 or to Logt and press the Menu Select button directly below Logt.
The display shows the User Login Indicator icon and Clear private data?.
2 Perform one of the following actions:
• Select Yes to clear all your private data. The display shows Private data cleared.
• Select No to keep your private data.
6.15
Text Messaging Service
Text Messaging Service (TMS) allows you to send and receive messages and run database queries
directly from your radios. The maximum number of characters allowed for a text message is 200
characters.
The types of text messages available are:
• A new text message (free form message).
• A predefined message (quick text message).
• An edited quick text message.
• A query (ASTRO 25 Advanced Messaging Solution).
NOTE: Query is only supported in the ASTRO 25 Advanced Messaging Solution. For more
information, see ASTRO 25 Advanced Messaging Solution and Two-Factor Authentication.
6.15.1
Accessing the Messaging Features
Procedure:
1 Perform one of the following actions:
