Number Description
9
†
4-Way Navigation Buttons
Use these buttons for list scrolling and navigating around the menu hierarchy.
10
†
Menu Select Buttons
Press to enter the menu corresponding to the button.
11
†
P Button
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
12 Dimmer Button
Press to adjust the display brightness.
Press and hold to toggle between day and night mode.
13 Accessory Port (Microphone)
14
†
Accessory No-Dot Button (Purple)
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
15 Push-to-Talk (PTT) Button
Press and hold to talk in simplex calls or to initiate a group call, release it to listen.
16
†
Accessory 1-Dot Button
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
17
†
Accessory 2-Dot Button
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
18
†
Data Feature Button
Press to enter the Text Messaging Service feature screen.
Press and hold to enter the Inbox menu.
19 Home Button (Microphone)
Press to return to the Home screen.
20 Navigation Button (Microphone)
Use these buttons for list scrolling and navigating around the menu hierarchy.
21 Cancel Button
Press to cancel the current operation and return to the previous screen.
22 Okay/Select Button
Press to select the option that appears on the screen.
23 Keypad Buttons
Use the keypad to enter alphanumeric characters for dialing, contact entries, and
text messages.
3.2
Keypad
Use the keypad to enter alphanumeric text on your radio.
MN006147A01-AE
Chapter 3: Radio Controls
21
