Table A-5 HDMI Connector Pin-outs
Pin Signal Name Description
1 Hot Plug Detect Detect HMDI Cable Present/ Reset HMDI Device
2 Utility Reserved
3 TMDS Data Channel 2+ Transition Minimized Differential Signaling Data Channel 2 positive
4 TMDS Data Channel 2
Shield
Transition Minimized Differential Signaling Data Channel 2 Shield
Ground
5 TMDS Data Channel 2- Transition Minimized Differential Signaling Data Channel 2 negative
6 TMDS Data Channel 1+ Transition Minimized Differential Signaling Data Channel 1 positive
7 TMDS Data Channel 1
Shield
Transition Minimized Differential Signaling Data Channel 2 Shield
Ground
8 TMDS Data Channel 1- Transition Minimized Differential Signaling Data Channel 1 negative
9 TMDS Data Channel 0+ Transition Minimized Differential Signaling Data Channel 0 positive
10 TMDS Data Channel 0
Shield
Transition Minimized Differential Signaling Data Channel 0 Shield
Ground
11 TMDS Data 0- Transition Minimized Differential Signaling Data Channel 0 negative
12 TMDS Clock+ Transition Minimized Differential Signaling Clock positive
13 TMDS Clock Shield Transition Minimized Differential Signaling Clock Shield Ground
14 TMDS Clock- Transition Minimized Differential Signaling Clock negative
15 CEC Consumer Electronics Control
16 Ground System Ground
17 SCL Display Data Channel I2C Clock
18 SDA Display Data Channel I2C Data
19 Power (+5V) +5 VDC Power out, 50 mA max.
