4 - 2 ET1 Enterprise Tablet Integrator Guide
Figure 4-1
Data Capture with Scan Module or Scan/MSR Module
4. The Decode LED lights green, a beep sounds and the ET1 vibrates, by default, to indicate the bar code
was decoded successfully. The captured data appears in the text field.
Using the Camera
To capture bar code data:
1. Ensure that an application is open on the ET1 and a text field is in focus (text cursor in text field).
2. Aim the rear-facing camera at a bar code.
3. Press and hold either Scan/Action button. By default, a preview window appears on the screen. The
Decode LED lights red to indicate that data capture is in process.
Figure 4-2
Data Capture with Rear-facing Camera
4. Move the ET1 until the bar code is centered.
5. The Decode LED lights green and a beep sounds, by default, to indicate the bar code was decoded
successfully. The captured data appears in the text field.
