Specifications A - 13
Scanning/MSR Module
Table A-14
Scanning/MSR Module Technical Specifications
Feature Description
Dimensions (W x L x H) 4.14 cm x 7.91 cm 3.97 cm (1.63 in. x 3.11 in. x 1.56 in.)
Weight 55.9 g (1.97 oz)
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Humidity 5% to 95% non-condensing
Drop 4 ft. (1.22 m) drops to concrete
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
Magnetic Stripe Reader
Interface USB
Format ANSI, ISO, AAMVA, CA DMV, user-configurable generic format
Swipe Speed 127 to 1270 mm (5 to 50 in.) /sec, bi-directional
Decoders Generic, Raw Data
Mode Buffered, unbuffered
Track Reading Capabilities Tracks 1 and 3: 210 bpi
Track 2: 75 and 210 bpi, autodetect
Security Built-in encryption engine
DES, Triple DES and AES Encryption
DUKPT key management
In-head electronics to prevent tempering
Scan Engine
Field of View Horizontal - 39.2°
Vertical - 25.4°
Optical Resolution 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Outdoor: 9000 ft. candles (96,900 lux)
Focal Distance From center of the exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm LEDs (2x)
