Set the antenna in its receptacle and turn
clockwise.
Caution:
If antenna needs to be replaced, ensure that
only MOTOTRBO antennas are used.
Neglecting this will damage your radio.
Attaching the Carry Holster
Follow the procedure to attach the carry holster to
your radio.
1 Align the rails on the carry holster with the grooves
on the battery.
2 Press downwards until you hear a click.
Attaching the Universal Connector Cover
(Dust Cover)
The universal connector is located on the antenna
side of the radio. It is used to connect MOTOTRBO
accessories to the radio. Follow the procedure to
attach the dust cover to your radio.
Replace the dust cover when the universal connector
is not in use.
12
English
