• DLN6986A, TETRA CRYPTR Micro AES256
IMPORTANT: The following procedure must be performed only in non-hazardous environment.
Prerequisites:
Your radio is equipped with a SIM/microSD card slot.
Prepare T-5IP TORX – PLUS screw bit and 1.0 ±0.1 in-lbs torque screwdriver.
Procedure:
1 Remove the battery.
2 Remove the SIM card door (see Installing the SIM Card on page 21).
3 Slide the SIM card holder toward the dust cover side of the radio (as indicated by the UNLOCK
arrow) to unlock it and lift it up.
4 Slide the microSD card holder toward the top of the radio (as indicated by the UNLOCK arrow)
to unlock it and lift it up.
MN006260A01-AG
Chapter 2 : Getting Started
25
