MTR3000 Backplane: Description 6-17

Table 6-12 J2 Option 2 Connector, Row A Pins

Pin # Pin Assignment To/From

1 Spare A14 –

2 GND Station ground

3 5VDC P8 pins 7, 8

4 GPIO_9 J1-A4, J3-A13, J4-A4, J5-C29

5 Spare A16 J1-A5

6 Spare A19 J1-A6

7 MOSI P7-8, J1-A7, J3-A7, J4-A7

8 GND Station ground

9 GPIO_10 J1-A9, J3-A17, J5-C24

10 OP2 CS2* J3-A11

11 Spare N/C

12 Spare N/C

13 Spare N/C

14 GND Station ground

15 14.2 VDC P8 pins 3, 4 (through F1)

16 Spare N/C

17 GND Station ground

18 GND Station ground

19 Spare N/C

20 Spare N/C

21 GND Station ground

22 RSSI J1-A22, J3-A22, J5-C11

23 Ext PTT* J1-A23, J3-A23, J5-C10

24 Reserved –

25 OPT_IRQ* J1-A25, J3-C23

26 Reserved –

27 Reserved –

28 Reserved –

29 Reserved –

30 GP1 Out WCO J1-A30, J5-C3

31 Reserved –

32 Reserved –
