11-2 MTR3000 Test Equipment And Service Aids: Service Aids
11.2 Service Aids
Table 11-2 lists the service aids recommended for working on the MTR3000 Base Station/Repeater
(BR). While all of these items are available from Motorola, most are standard workshop equipment
items, and any equivalent item capable of the same performance may be substituted for the item
listed.
Table 11-2 Service Aids
Motorola
Part Number
Description Application
DDN9957A Standard Type "A" to Type "B"
USB Programming cable
To connect a service computer to the MTR3000 Base
Station/Repeater’s front USB port for Programming,
Testing and Alignment.
HSN1006 Speaker To listen to any active audible alarms
Note : The speaker port on the base station/repeater is
compatible with Service Speaker HSN1000 (older
model) or HSN1006.
3083191X02 RJ-45 to BNC cable / Receiver
Audio Test Cable
Connects the external speaker RJ-45 jack to the
Oscilloscope input BNC connector
GMMN4063 Microphone To transmit voice by connecting it to microphone
connector on SCM
Note : The microphone port on the base station/repeater
is compatible with microphone GMN6147 (older model)
or GMMN4063. The older model of microphone
(GMN6147) only works in analog mode and does not
support the 3 control buttons for speaker volume
control, Rx monitor and Intercom control functions.
0185180U01 Speaker adapter cable To connect the speaker to speaker connector on SCM
RVN5115 Customer Programming
Software (CPS) Package
(Includes CPS, Air Tracer,
Tuner, Radio Diagnostic and
Control (RDAC))
Program customer option and channel data
6683334X01 Option Card Tool To pull the option boards (such as the Wireline Interface
Boards or the Auxiliary Input/Output board)
