14-16 MTR3000 Maintenance and Disassembly/Reassembly: Parts List
14.9 Parts List
Table 14-3 MTR3000 Exploded View Parts List
Item No. Description Part Number
1 Top/Bottom Chassis Plate 15009086001
2 Option Card Bracket 0782635X03
3 Auxiliary I/O Board (FRU)
*
CLN1206_
4 4-wire Wireline Board DLN6720_
5 Backplane Interface Board CLN8499_
6 Backplane Interface Board Shield 26009131001
7 Fan Grille (Power Amplifier or Power
Supply)
1383852R01
8 Power Amplifier Fan 59009254002
9 Power Amplifier (FRU) Refer to Section A.1.2 on page A-4
10 Receiver Module (FRU) Refer to Section A.1.2 on page A-4
11 Station Control Module (FRU) Refer to Section A.1.2 on page A-4
12 Station Control Module Front Panel 64009266001
13 Front Bezel 6475414H01
14 Exciter Module (FRU) Refer to Section A.1.2 on page A-4
15 Power Supply Fan 59009254001
16 Power Supply (FRU) DLN6707_
Note (*) Not available for the 800/900 MHz band.
